Chaska 29

Gas insert fireplace available with a traditional log set, glass media set or a rock media set.

  • tick-icon Fireplace Type: Gas Inserts
  • tick-icon Material: Rock, Glass, Log
Share this twitter-white facebook-white google-plus-white pinterest-white
Product Information
Features:
  • Comes in Log, Glass or Rock media
  • Viewing Area: 12 5/8” x 25 7/8”
  • 30,500 BTU/hr Input NG
  • 30,000 BTU/hr Input
  • Electronic Ignition Pilot System
  • Co-Linear Air Duct –Accepts 3” Combustion Air / 3” Exhaust
  • Ceramic Glass
  • Fan Kit
  • Traditional Brick Refractory
  • Standard Ember Light Kit
  • Certified to ANSI Z21.88 Vented Gas Heater
Efficiencies
  • Log and Rock
    • ENERGUIDE P.4 NG/LP | 72.27%/72.36%
    • Steady State NG/LP | 74%/74%
    • AFUE % NG/LP | 71%/72.12%
  • Glass
    • ENERGUIDE P.4 NG/LP | 60.8%/63.21%
    • Steady State NG/LP |72.21%/72.26%
    • AFUE % NG/LP | 66.62%/66.09%
  • MV
    • ENERGUIDE P.4 NG/LP |71.26%/71.33%
      Steady State NG/LP | 74%/74%
      AFUE % NG/LP |71%/72.12%
  • Efficiencies Glossary:
    • P.4 Efficiency (ENERGUIDE) is an efficiency rating more recognized in Canada to measure annual fireplace efficiency.
    • Steady State Efficiency is a measure of how efficiently your fireplace converts fuel to heat once it is warmed up and operating at a steady temperature.
    • Annual Fuel Utilization Efficiency (AFUE) is a measurement of the fireplace’s ability to convert fuel to heat over a longer period of time including the cycling on and off time period.
  Design Standard Features
  • Traditional Brick Refractory
    • Chaska 29 Log and Chaska 29 Millivolt only
  • Black Enamel Refractory
    • Standard on Chaska 29 Rock and Chaska 29 Glass only
  • Ember Light Kit
    • Standard on Chaska 29 Log and Chaska 29 Rock only
  • Accent Light Kit
    • Standard on Chaska 29 Glass only
  • Screen Front
    • For options and pictures, look at the Chaska brochure under the Resources tab.
  Required Design Features
  • Glass Media Kit
    • For options and pictures, look at the Chaska brochure under the Resources tab.
  • Screen Front
    • For options and pictures, look at the Chaska brochure under the Resources tab.
Optional Features:
  • Black Enamel Lining
    • Optional for Chaska 29 Log
Required for Installation:
  • 1 Piece Shroud ( Standard or custom size)
